Nobsound VU1-W 4-IN-1-OUT Audio Switcher with VU Meter

• Seamless Audio Switching: Experience effortless audio management with four input channels. VU1-W accommodates your needs for switching between different audio sources, ensuring pure, uncolored sound.
• Elegant Wood Casing for Vintage Touch: The high-quality pure walnut wood casing, complementing the rhythmic pulse of the VU meters, offers a natural and warm design that adds sophistication and vintage charm to your desk audio system.
• Remote Control Convenience: With a compact footprint and user-friendly remote control, the VU1-W is perfect for desktop use. Adjust the gain, sensitivity, and brightness settings effortlessly from a distance, creating a personalized, visually appealing, and functional workspace.
• Versatile for Various Scenarios: The VU meter spectrum display supports MIC pickup, vividly showcasing every beat of the music without wiring, plus a headphone output for personal listening. These convenient designs makes it a perfect fit for any home office, studio, or entertainment space.
• With Precision Tone Control: Fine-tune your audio experience with precise treble and bass adjustments. Shape the audio to your exact preferences without any additional costs, making it ideal for users who demand a personalized audio experience.

• Brand: Nobsound
• Model: VU1-W
• Diameter of VU meter: 45mm
• Audio input: Stereo RCA / AUX / MIC pick-up
• Audio output: Stereo RCA / 3.5mm headphone jack
• Working mode: 4-IN-1-OUT
• Frequency response: 20Hz-20KHz
• THD: 0.01%
• SNR: >98dB
• Max. input level: 0.775Vrms
• Net Weight: 532g / 1.17lb
• Max. Output level: 2.5Vrms
• Matched headphone impedance: 16-200Ω
• Headphone output power: 50mW@32Ω
• Bass/treble range: ±10dB
• Backlight brightness: 5 levels
• GAIN: 10 levels
• Sensitivity: 10 levels
• MIC pick-up: Support
• Remote control: Support
• Settings saved after shutdown: Support
• Working voltage: DC 5V (≥1A)
• Power interface: Type-C
• Dimensions (W*D*H): 121*55*83mm / 4.76*2.17*3.27in
• Package dimensions (W*D*H): 215*185*100mm / 8.46*7.28*3.94in
• Net weight: 321g / 0.71lb
• Package weight: 600g / 1.32lb

FAQs

FAQs

Q: Can the BS-2 be used as a regular speaker?
A: No. It is designed for low-frequency tactile feedback, not full-range sound playback.
Q: What amplifier should I use with the BS-2?
A: Use a bass shaker amplifier or compatible subwoofer amp with low-pass filter, such as the Douk Audio G100. A regular 4Ω amp can also drive it, but the vibration effect may be less ideal with full-range signals.
Q: How much amplifier power is safe for the BS-2?
A: The BS-2 is rated at 30W, with 50W max input power and 4Ω impedance. Do not exceed 50W per unit. For long-term use, keeping output closer to 30W is recommended.
Q: Can I connect multiple BS-2 units together?
A: Yes, but total impedance changes with wiring. Two units in series equal about 8Ω, while two in parallel equal about 2Ω. Always confirm your amplifier supports the final impedance before use.

• The enclosure is crafted from solid walnut wood and each unit features unique grain patterns, so the actual product may have slight variations in details compared to the pictures.
• VU1-W needs to be powered by an independent DC 5V (≥1A) USB power supply.
• 3.5mm headphone jack output with priority, please make sure the headphone has been disconnected if you want RCA output.
• The VU1-W doesn’t support 1-IN-4-OUT.
• For safer and faster delivery, the remote control does not include batteries (AAA*2), please prepare it yourself.
