Douk Audio ST-01 PRO HiFi Bluetooth 5.0 Tube Amplifier USB DAC COAX/OPT Digital Audio Amp w/VU Meter
- With 5 kinds of analog and digital audio input (Bluetooth 5.0 / PC-USB / U-disk / Coaxial / Optical / 2 groups of RCA), compatible with almost all audio devices such as MP3, phone, tablet, computer, TV, CD players etc. U-disk input supports lossless formats such as APE, FLAC, WAV etc., easy to enjoy HiFi music.
- Multiple audio outputs for different devices: besides speaker output, add 3.5mm headphone jack out to improve sound quality for headphones, and a low frequency output is specially designed to connect active subwoofer to build 2.1 channel audio system and strengthen bass sound effects.
- Combined design of tubes and transistors: using 6P17A as preamplification, the sound is clear, warm, smooth and delicate with high fidelity. 2PCS Toshiba C5198 and 2PCS 1941 triode for power amplification, each channel can output 25W, easily to drive all home passive speakers.
- Vintage looking specially with VU meter: exquisite black panel matches with retro vacuum tubes and VU meter to dynamically to decorate home desktop space. With independent function buttons and input indicators on the top panel, easy to use, very suitable for home and desktop audio system use.
- Audio input: Bluetooth 5.0 / Optical / Coaxial / PC-USB / U-disk / 2 groups of stereo RCA
- Audio output: banana speaker jacks /3.5mm headphone jack / low frequency out (connect active subwoofer)
- USB supported sampling rate: 16Bit/48kHz
- U-disk supported formats: MP3/WMA/WAV/APE/FLAC
- U-disk max storage capacity: 128G
- Coaxial/Optical sampling rate: 16Bit/48kHz
- Bluetooth version: 5.0
- Power consumption: 70W
- Output power: 25W+25W @4Ω 17W+17W @8Ω
- Headphone matching impedance: 16-600Ω
- Headphone output power: 10mW@32Ω
- Input impedance: 47KΩ
- Output impedance: 4-16Ω
- Input sensitivity: 600mV
- Frequency response: 20Hz-20kHz (±2dB)
- SNR: ≥89dB
- Distortion(1kHz): 0.10%
- Separation: ≥75dB
- Working voltage: 110V/220V
- Dimensions(W*D*H): 170*170*120mm/6.69*6.69*4.72in
- Pacakge dimensions(W*D*H): 240*240*250mm/9.45*9.45*9.84in
- Net weight: 1.54kg/3.04lb
- Package weight: 2.5kg/5.51lb
- Tube Amplifier ×1
- Power Cord ×1
Warm tips:
- Only in the condition of large dynamic music and much bass effect the VU meter will work.
- When inserting the tubes please pay attention to the direction, the arrow on the tube should be aligned with the bulge on the tube socket.
- 6P17A vacuum tubes are not easy to be found on web. But its unique performance will bring you an unforgettable sound experience. If you want more spare tubes, please contact us directly.
Retro classic warm tube sound
Convenient key operation to switch inputs & PREV / NEXT & Play / Pause
Unique VU meter design
Smooth volume knob
Support Bluetooth & PC-USB & U-Disk inputs
Support optical & coaxial & RCA inputs and subwoofer & headphone outputs
Solid binding posts for both raw speaker cables and banana plugs
Replaceable built-in protective fuse
Customer Reviews
jakości, dzwięku, funkcji i wykonania.
ciepło dzwięku z szorstkiej oprawie.
There is absolutely no information about the type of Dac.
The media could not be loaded.
El equipo es pequeño pero suena fenomenal suficientes para Wharfedale Evo 4.2Envío y empaque todo perfecto
I don't like at all the location on and off switch.
I really wanted to like this and have it be my long term solution.The size is great for a desktop, the sound is great, the build quality is excellent. They really did a good job with the fit and finish of the cabinet.My main problem is with the power button. It is situated on the backside, amongst all the wires and connectors. I like to turn my electronics off when I am not using them so they don't drain energy. With this unit, it was inconvenient to get to the button, and worse, the fiber optic cable comes out almost every time I fumble around on the back to turn it off.One minor gripe is that I love the little gauge on the front, but it only moves when you really have the sound cranked up. Using it for my desktop volume doesn't even move the needle.The design is a little polarizing. I like it, but my wife came in, took one look and said, "What, are you going for the mad scientist look now?"If you don't need to turn this off regularly, it is a great little amp!
