User Manual of Douk Audio U2 PRO
Warm tips:
- The U2 PRO supports Windows 10/11, macOS, Android, and iOS. Windows 10 and above can run driver-free for PCM playback up to 384kHz, but higher sampling rate and DSD playback requires driver installation. macOS works driver-free. To avoid potential compatibility issues, it is not recommended to use Windows 7/8, or general-purpose Linux systems. Linux-based audio systems like Daphile, Volumio, and ROON are supported.
- The U2 PRO supports oscillator replacement (not pluggable, needs soldering). Default 24.000 MHz ±20 PPM 5032 active oscillator, can be replaced by DIP-4P rectangular plug-in active oscillators or 5030 SMD active oscillators.
- The U2 PRO only supports 2.0 channel stereo audio. Multichannel formats such as 5.1, 7.1, or Dolby formats are not supported.
- Please install the required driver and files from the included USB drive, and follow the instructions or video guide to set up your player properly.
- Unlock Pristine Lossless Audio: Easily convert the USB signal from your PC, Mac, phone or Raspberry Pi etc. into clean and simultaneous outputs of Optical, Coaxial and I2S. Feed a clear, stable, and jitter-free digital signal to those classic DACs, amplifiers and AV receivers without USB input for an immediate sound quality upgrade.
- Ultra-high Resolution with XMOS XU316: Equipped with the latest XMOS XU316 chip, the U2 PRO ensures virtually no latency, stable signal transmission, and exceptional sound clarity. Supports PCM up to 32bit/768kHz and DSD512, perfect for high-end music streaming and professional audio playback.
- Strong Compatibility via UAC Mode Switch: Specially designed with a UAC mode switch, the 1.0 mode offers plug-and-play, driver-free compatibility for gaming consoles like PS4, PS5 and Switch, while 2.0 mode enables high-resolution audio support for advanced playback needs.
- Expandable Oscillator Design: With ample internal space to accommodate compatible crystal oscillators, the U2 PRO lets audiophiles and DIYers freely upgrade their preferred high-precision clock to further reduce jitter and achieve an even higher level of sonic performance and system synergy.
- Compact Size with Convenient Indicators: Pocket-sized and USB-powered, the U2 PRO includes a USB-C to USB-A/C cable for broad device compatibility—truly plug and play. Real-time PCM/DSD indicators make it easy to monitor sample rates and formats. A simple yet powerful upgrade for audiophiles, gamers alike.
- Brand: Douk Audio
- Model: U2 PRO
- Audio input: USB Type-C
- Audio output: Coaxial/Optical/HDMI-IIS
- USB chip: XMOS XU316
- Output mode switch: UAC 1.0/UAC 2.0
- Max. sampling rate Coaxial/Optical supported:
PCM:44.1kHz-192kHz/16Bit-24Bit
DSD:DOP DSD64 - Max. sampling rate IIS supported:
PCM:44.1kHz-768kHz/16Bit-32Bit
DSD (Native): 64-512
DSD (DOP): 64-256 - Operation systems PC-USB supported: W10/W11/Mac OS/Android/iOS/PS5/Switch
- Jitter: 75ps (typical)
- THD+N: 0.000008%
- Working voltage: DC 5V
- Dimensions (W*D*H): 85*79*26mm / 3.35*3.11*1.02in
- Package dimensions (W*D*H): 195*155*70mm / 7.68*6.10*2.64in
- Net weight: 220g / 0.44lb
- Package weight: 400g / 0.88lb
- U2 PRO Digital Interface ×1
- Optical Cable ×1
- USB-C to USB-A/USB-C Cable ×1
- User Manual ×1
Hear What They Say about the K5

Old Guy Hifi
Douk K5 it’s a cool little audio device. It’s the perfect unit for small spaces like a Dorm Room.

UTILITARIAN TV
Can a £90 DAC Beat a £450 DAC?

MrJayBee Intl
DOUK AUDIO K5 USB DAC Headphone Amplifier | Best DAC under 120$?


Elevate Your Digital Audio Experience
U2 PRO delivers high-resolution audio up to PCM768kHz and DSD512. Flexible output, virtually no latency with XMOS XU316, switchable UAC modes and game console support make it perfect for audiophiles and gamers alike.
