Warm tips：
The A5 with 2PCS pluggable NE5532 op-amps, can be upgraded by dual op-amps like 2134/2604/5532/2068/muse02 etc.
- HiFi Sound with Adjustable High-Pass Filter: This TPA3255 amplifier features an adjustable high-pass filter (HPF) 30-200Hz to refine mid-high frequencies while minimizing low-frequency interference. Perfect for bookshelf or passive speakers, it enhances clarity and creates a dynamic soundstage ideal for home stereo and theater audio systems.
- Easy Customization with Plug-and-Play Op-Amps: Upgrade your sound effortlessly! Douk Audio A5 includes a tempered glass access panel for quick op-amp replacements, allowing audiophiles to tailor sound profiles without disassembling the unit.
- PFFB Technology and High-Performance PCB: Built with Post-Filter Feedback technology circuit and a 4-layer immersion gold PCB, this digital amplifier reduces distortion and improves frequency response. Enjoy unparalleled audio precision, enhanced signal integrity, and effective heat management.
- Stunning Design for Living Rooms and Studios: Sleek and modern, the compact power amp is equipped with a transparent panel and adjustable internal LED lighting. Multiple color options create a futuristic look, adding sophistication to your home audio setup or studio.
- 300W×2 Power with Premium Components: Powered by the TPA3255 chip and premium components, A5 delivers distortion-free audio with ultra-low THD (0.002%) which is perfectly compatible with the DAC-Q11. Whether you’re enjoying weekend movie nights, evening music sessions, or after-work relaxation, A5 can deliver exceptional sound quality.
- Brand: Douk Audio
- Model: A5
- Audio input: Stereo RCA
- Audio output: Banana speaker jacks/3.5mm AUX
- High-pass filter adjustment range: 30Hz-200Hz
- Max. output power: 300W*2 (4Ω)
- Matched speaker impedance: 4-8Ω
- THD+N: 0.002%
- SNR: ≥114dB
- Input sensitivity: 2V
- AUX rated output level: 3.7V
- Frequency response: 20Hz-20kHz (±0.7dB)
- Working voltage: DC 24-48V
- Dimensions (W*D*H): 95*92*50 / 3.74*3.62*1.97in
- Package dimensions (W*D*H): 265*240*65mm / 10.43*9.45*2.56in
- Net weight: 506g / 1.12lb
- Package weight(with 32V5A power supply): 1100g / 2.43lb
- Package weight(with 48V5A power supply): 1200g / 2.65lb
Power Output Table of Douk Audio A5
Power Supply | Speaker Impedance | Rated Output Power |
|---|---|---|
32V/5A | 4Ω | 78W+78W |
32V/5A | 6Ω | 71W+71W |
32V/5A | 8Ω | 65W+65W |
36V/6A | 4Ω | 107W+107W |
36V/6A | 6Ω | 100W+100W |
36V/6A | 8Ω | 94W+94W |
48V/5A | 4Ω | 120W+120W |
48V/5A | 6Ω | 110W+110W |
48V/5A | 8Ω | 102W+102W |
48V/10A | 4Ω | 250W+250W |
48V/10A | 6Ω | 210W+210W |
48V/10A | 8Ω | 185W+185W |
- A5 Amplifier ×1
- DC 32V/5A Power Adapter(Optional) ×1
- DC 48V/5A Power Adapter(Optional) ×1
- User Manual ×1
@New Record Day
Cheap Amp Destroys Most “Audiophile Amps”?! (silly clickbait title)
@cheapaudioman
Cheap Amp Sounds Awesome and Does things Differently
@Audio Science Review
Douk Audio A5 Stereo Budget Amplifier Review
Kiváló termék.
Great little amplifier!
The amp is amazing. Two changes I would like to see: the glass door on top should be hinged or made of plexiglass as I successfully broke it before I ever got the amp installed. Second, clearly mark thelow filter settings to assist in dialing in the correct frequency.
This is an excellent amplifier at an unbelievable price. I would recommend it highly.
Not just great for the money! Audiophile Reference level out of the box, and once cheaply modified, beyond critique!Listen folks, I'm a nutty audiophile. I've heard and owned all sorts of amps, both tube and solid state, amps costing as much as 10k+. When I had to send an Enleum Amp23r (6.5k retail) to South Korea for servicing, based on chatter amongst respected audiophiles, I figured I'd experiment with this Douk amp. I paid my $120 for the 48v version. I also ordered Sparkos ss3602 Op Amps for $150. Before getting the op amps in, I was super impressed with the performance of the Douk, although it fell short of the best I'd owned, it was much better than most amps under 2kish in price! Mind you, I was and am still sourcing the Douk with a 5k DAC/Streamer called the Wattson Madison LE (designed and built in Switzerland). The modified Douk is totally up to the task of amplifying one of the best digital sources in the world! I've recently added a 1.5k, all analog preamp (Ladder Chopin) in front of the Douk, and that has proved a perfect match. The op-amp modified Douk is beyond critique!This is an unreal amp! It is my reference amp, and costs 1/8th the price of the speaker cables connected to it! WTF!
