[Pre-Sale] Ampapa H1 Class A Headphone Amplifier 4000mW with TRS/RCA P

[Pre-Sale] Ampapa H1 Class A Headphone Amplifier 4000mW with TRS/RCA Preamp

No reviews

$169.99

Features

Power for Demanding Headphones
Preamp Control for Your Audio System
Custom ECC83 Tube Character
Effortless Control Across Your Setup
Built for Refined HiFi Use

SHIPPING FROM

China

Shipping Notice:
US orders will be shipped around June 20,
while orders for all other regions will be shipped around June 1 .

Free Shipping

2-8 Days Arrival

30-Day Return

2-Year Warranty

Ampapa D1 HIFI TPA3255 Amplifier with Digital VU Meter

Ampapa Q1 HIFI ESS9039+AK4493 Desktop DAC [Based on DAC-Q11]

Ampapa Q1 HIFI ESS9039+AK4493 Desktop DAC [Based on DAC-Q11]

Ampapa BK1 Aluminum Desktop HiFi Stand for A1/D1/Q1

Ampapa BK1 Aluminum Desktop HiFi Stand for A1/D1/Q1

1.jpg__PID:1f4dbdd8-6dff-4b12-86a2-53c82bd3b40a

@v-mire.net

Why everyone praises the Ampapa D1 amplifier with TPA3255 2x 300W

3.jpg__PID:1036d43b-5383-4e0a-a65a-225e90ae8c2a

@Williston Audio Labs

This Little Amp Has a SHOCKING Feature

4.jpg__PID:9add34e6-6820-463f-b50c-da18381523f5

@Souzoukan Technical Report

Revealing the performance of the Chinese-made Ampapa D1 with a glass window

7.jpg__PID:e27b1893-3c08-449f-ba61-71ad57ac33d0

@HiFi Huff

FUN! Comparing SIX Integrated Amps from $199 to $25,000. Also, are Separates BETTER?

6.jpg__PID:5c083057-9f09-4c00-bc1d-980613507fb6

@Old Guy Hifi

Not in price but in Performance! The Ampapa (Douk) D1 Hifi Amp.

8.jpg__PID:533890a7-db31-4d9b-96d1-eeb39b375d6d

@Christian Schwarzbeck - China-HiFi

Ampapa D1 – Der kompakte High-Tech-Verstärker mit 3 Eingängen, VU-Metern, PFFB & Hochpassfilter!

FeaturesParametersPacking ListUser Manual/FAQs

Power for Demanding Headphones: Built around a discrete Class A output stage, Ampapa H1 delivers strong current drive and up to 4000mW from its balanced high-gain output, giving 16–600Ω headphones wider headroom, steadier control and smoother dynamics. 4.4mm, 4-pin XLR and 6.35mm outputs fit more full-size HiFi headphone setups.
Preamp Control for Your Audio System: With 2×RCA and 1×TRS analog I/O, H1 keeps your DAC, CD player and streamer connected for simple source selection, while its preamp outputs can stay linked to multiple power amps or active speakers for system expansion. Designed to complement Ampapa Q1 and D1, it adds tube preamp control for a more unified stack.
Custom ECC83 Tube Character: Made with exclusive PSVANE × Douk Audio ECC83 tubes, H1 brings a warmer, richer tube character to both headphone listening and preamp output. The custom tube set gives H1 a more distinctive out-of-box identity, while tube rolling support leaves room to fine-tune the sound later.
Effortless Control Across Your Setup: Low, mid and high gain help H1 match sensitive headphones, everyday models and harder-to-drive pairs with less guesswork. HP, Line and HP+Line output modes cover headphone, preamp output or both, while the 1.5-inch OLED keeps key status clear and 12V Trigger helps compatible gear power on/off together.
Built for Refined HiFi Use: Japan NJW1195 volume IC keeps channel balance stable, while pluggable op-amps leave room for sound tuning. 0.04% THD+N and ≥113dB SNR support clean signal performance, and the low-noise relays, isolated tube power shielding and CNC aluminum chassis add quieter operation and lasting build quality for demanding headphone listeners or serious HiFi users.

Brand: Ampapa
Model: H1
Audio Inputs: 2 × RCA Inputs / 1 × TRS Input
Audio Outputs:
2 × RCA Outputs / 1 × TRS Output
4-Pin XLR / 6.35mm / 4.4mm Headphone Outputs
THD+N: 0.04%
SNR: ≥113dB
Frequency Response: 20Hz–20kHz (±0.7dB)
Input Sensitivity: RCA: 1V ; TRS: 2V
Rated Output Level (by Gain):
RCA Output: High-3.0V ; Mid-2.1V ; Low-1.5V
TRS Output: High-6.0V ; Mid-4.3V ; Low-3.0V
Rated Headphone Output Power (by Gain):
Balanced Output: High-4W ; Mid-2W ; Low-1W
Single-Ended Output: High-1000mW ; Mid-500mW ; Low-250mW
Matched Headphone Impedance: 16–600Ω
Power Input: DC 12V / ≥2A, 5.5 × 2.1mm
Dimensions (W*D*H): 155 × 124 × 42mm / 6.10 × 4.88 × 1.65in
Package Dimensions: 268 × 192 × 95mm / 10.55 × 7.56 × 3.74in
Net Weight: 750g / 1.64lb
Package Weight: 1.28kg / 2.82lb

1 × H1
2 × ECC83 Tubes
1 × DC 12V Power Adapter
1 × 6.35mm to 3.5mm Adapter
1 × 3.5mm Trigger Cable
1 × Certificate
1 × Warranty
1 × Cleaning Cloth
1 × User Manual

User Manual of AMPAPA H1

FAQs

Q: Can I use multiple headphone outputs at the same time?
A: The 6.35mm output has priority. When a 6.35mm plug or adapter is inserted, the 4.4mm and 4-pin XLR outputs are disabled. For best performance, we recommend using one headphone output at a time.

Q: How should I choose the gain setting?
A: Use Low Gain for sensitive or low-impedance headphones, Mid Gain for most daily listening, and High Gain for high-impedance or harder-to-drive headphones. Start low, then increase the gain if more volume or drive is needed.

Q: Can I replace the tubes?
A: Yes. H1 uses ECC83 tubes and supports compatible tube rolling with 12AX7, 7205, 6N4 and 5751 tubes. Always power off the H1 before replacing tubes, and confirm compatibility before trying other tube models.

Q: Can I replace the op-amps?
A: Yes. H1 uses two pluggable LME49720 op-amps and supports replacement with standard DIP-8 dual op-amps such as OPA2604, OPA2134 and MUSES02. Please power off the H1 before replacement and check chip orientation carefully.

Q: What power adapter should I use?
A: Please use the included DC 12V/2A power adapter. If using another adapter, choose a high-quality DC 12V adapter rated at 2A or higher. Do not use an adapter with excessive voltage.

More Control in One Preamp

Douk Audio H5 Tube Preamp

From MM phono and RCA input to HPF, dedicated SUB Out, LPF, tone control, and dual RCA outputs, H5 gives vinyl, stereo, and 2.1 setups more ways to connect, tune, and expand.

Vintage Soul for Modern HiFi

Douk Audio T12 Tube Preamp

A tube preamp that blends MM/MC phono, RCA line input, switchable outputs, tone control, and headphone listening with classic HiFi style.

Vintage Soul for Modern HiFi

Douk Audio T12 Tube Preamp

A tube preamp that blends MM/MC phono, RCA line input, switchable outputs, tone control, and headphone listening with classic HiFi style.

Vintage Soul for Modern HiFi

Douk Audio T12 Tube Preamp

800-600.jpg__PID:092c9fbd-b89f-4410-b865-1fc8f55a8807

Ampapa H1 & Q1 & D1

Unlock the Full Ampapa Experience

H1 joins D1 and Q1 with matching design language and system-ready connectivity. Adds Class A headphone drive, tube warmth and preamp control, making the whole setup feel richer, stronger and more complete.

Input: 2×RCA / 1×TRS
Output: 2×RCA / 1×TRS / 4-Pin XLR,6.35mm,4.4mm
Headphone OutHeadphone Power: Up to 4000mW (Balanced Output, High Gain)
THD+N: 0.04%; SNR: ≥113dB

Max. 4000mW Out RCA/TRS Connectivity Versatile Headphone Out 3-Level Gain Output Modes
