Features
-
Dual microphone inputs for Karaoke everywhere: dual moving coil mic interfaces, with built-in DSP, great howling detection and suppression function, also support echo and vocal elimination, the best choice for you to build high-quality KTV room at home or in the car.
-
M7 with multiple audio inputs: mini digital amplifier, with 6 kinds of audio inputs (Bluetooth / USB / stereo RCA / coaxial / optical / microphone) and banana speaker output, compatible with most home audio devices such as phone, tablet, computer, TV, set-box, CD player etc..
-
Strong compatibility and high-quality sound: S/PDIF transmits stream bit-perfect 24Bit/192KHz HD low jitter signal to get better sound, USB input both supports PC-USB and U-disk, also can be a digital player to play lossless formats such as WMA / WAV / APE / FLAC besides MP3.
-
Sufficient output power and tone knobs: adopts Infineon MA12070 chip, max output reaches 80W+80W (AC version) / 68W+68W (DC version), easily to drive most home passive speakers (4-16Ω); music can be reproduced music with rousing highs and deep lows via adjusting treble / bass knobs.
- Attractive looking and advanced designs: besides LED display screen to show all items, clearly to know its working status in real time; also add RGB LED sound level meter to show the volume and dynamically decorate your listening space, very suitable for those audiophiles who pursue HiFi sound.
Warm tips:
1. Douk Audio M7 with two versions: AC 100-240V IN / DC 12-20V IN, the difference between them is in the output power (AC IN is 80W+80W, DC IN is 68W+68W), size and weight, totally the same in other aspects.
2. USB input mode only can be displayed and selected when the USB interface connected to a U-disk or the USB port of computer.
3. Previous / Next song / Play & Pause buttons are only valid in U-disk playback mode.
Parameters
| Version |
AC INPUT |
DC INPUT |
| Audio input |
Bluetooth / stereo RCA / Coaxial / Optical / USB (PC-USB/U-disk) / 2 groups of microphone |
| Audio output |
banana speaker jacks |
| Amp chip |
MA12070 |
| Bluetooth version |
5.0 |
| Matched impedance |
4-16 ohm |
| Max. output power |
80W+80W |
68W+68W |
| Max. Sampling rate supported |
24bit/192KHz (Coaxial / Optical) / 16bit/44.1Khz (USB) |
| File formats U-disk supported |
MP3 / WAV / WMA / APE / FLAC |
| Format U-disk supported |
FAT32 (not support NTFS) |
| Working voltage |
AC 100-240V |
DC 12-20V (5.5mm / 2.1-2.5mm) |
| Dimensions (W*D*H) |
95*158*137mm / 3.74*6.22*5.39in |
95*88*137mm / 3.74*3.46*5.39in |
| Package dimensions (W*D*H) |
230*120*160mm / 9.06*4.72*6.30in |
190*120*160mm / 7.38*4.72*6.30in |
| Net weight |
900g / 1.98lb |
495g / 1.09lb |
| Package weight |
1100g / 2.43lb |
900g / 1.98lb |
Packing List
-
1*M7 Amplifier
-
1*Power Cord
- 1*Power Adapter ( Only for DC Version)
